Industrial power connector designed for secure, rewirable mains connections. Peace of mind for installers who need a compact, rebuildable IEC C19 to C20 coupling. Is sourcing map IEC320 Rewirable Socket the reliable, space-saving connector your rack requires?
⚡ At a Glance
- • Electrical Rating: AC250V, 16A; Insulation Resistance ≥100M Ohm; Withstand Voltage ≥AC 2000V/min
- • Best for: Technicians and system installers needing rewirable C19 male to C20 female power connections
- • Not ideal for: Users wanting pre-terminated, plug-and-play power leads
Rewirable IEC320 C19 male and IEC320 C20 female designed for industrial mains connections. Technical ratings and compact dimensions suit rack-mounted equipment.
Flexible Installation - with rewirable C19 male and C20 female contacts
Screw-terminal style connections accept conductors through an 11mm wire hole, allowing on-site termination. Model numbers SS-810 (plug) and SS-809 (socket) indicate the rewirable pairing supplied in the package.
Enables custom cable lengths and orientations during rack builds and repairs, simplifying replacement and reducing downtime.
Reliable Electrical Performance - with high insulation and voltage withstand
Insulation resistance of at least 100M Ohm and a rated withstand voltage of AC 2000V per minute complement the AC250V, 16A mains rating. Measured insertion force of 5-30N ensures stable mating pressure.
Delivers steady power transfer and helps prevent intermittent connections in demanding installations.
Compact, Serviceable Design - with measured dimensions and light weight
Plug measures 83 x 35 x 27mm while the socket is 82 x 38 x 35mm; net weight is 107g. ABS housing provides a balance of impact resistance and manufacturability.
Fits into tight rack cutouts and remains easy to handle during installation or replacement without adding significant bulk.
✨ The 4 Key Reasons for sourcing map IEC320 Rewirable Socket
Rewirable Terminals - Enables custom cable lengths and on-site repairs quickly
Firm Insertion Force - 5-30N mating pressure reduces accidental disconnections
11mm Wire Entry - Accepts common conductor sizes for flexible wiring choices
Compact Footprint - Sits within tight cutouts at roughly 83 x 35 x 27mm
📋 Technical Details at a Glance
- Category: Industrial power connector
- Connector Type: IEC320 C19 male to IEC320 C20 female
- Model: SS-810 (plug), SS-809 (socket)
- Rating: AC250V, 16A
- Insulation Resistance: ≥100M Ohm
❓ Frequently Asked Questions
Q: Is the connector rewirable?
A: Yes, the connector uses rewirable screw terminals that allow on-site termination and flexible installation.
Q: What electrical ratings does it support?
A: Rated for AC250V at 16A with an insulation resistance of at least 100M Ohm and a withstand voltage of AC 2000V per minute.
Q: What are the dimensions and weight?
A: The plug measures 83 x 35 x 27mm, the socket 82 x 38 x 35mm, and the net weight is 107g.
🏆 Our Verdict
Suited to technicians and system installers who need rewirable IEC connections for rack equipment. The key selling point is on-site rewirability combined with solid electrical ratings and a compact form. Offers practical long-term value through repairability and reliable construction.
